Automatic SMT online lead free dual DIP wave soldering machine for PCB 350
Machine technical parameters |
| 300 series | 350 series |
| 300 | 350 |
PCB board adjustable width | Max.50-300mm | Max.50-350mm |
PCB board transport height | 750±50mm |
PCB board transport speed | 0-2000mm/Min |
PCB board transport angle (welding angle) | Standard 5.5 degree fixed: adjustable +0.5 degrees or -0.5 degrees |
PCB board transportation direction | L→R/R→L(option) |
Component height limit on PCB | Max.80mm-120mm |
Preheating zone length | 1500mm |
Number of preheating zones | 3 segments |
heating method | Hot air |
Number of cooling zones | 1pcs |
Tin furnace power | 7kw |
Tin furnace tin content | 280KG | 330KG |
Tin furnace temperature | Room temperature~300℃ |
Temperature control method | P.I.D+SSR |
Machine control mode | Siemens PLC + Siemens temperature module control |
power supply | 3-phase 5-wire system 380V |
Starting power | max. 7kw |
Air supply | 0.3-0.6Mpa |
Dimensions | L3200×W1300×H1650MM |
Spray nozzle moving system | Driven by stepper motor, the moving speed is average, stable and reliable |
Temperature control mode | Siemens temperature acquisition module, PID temperature control is accurate and reliable, imported thermocouple detection system, with thermocouple abnormal alarm function. |
Adjustment mode | Manual adjustment |
Manual adjustment | Japan Matsushita frequency conversion stepless speed regulation 90W motor with overload limiter protection device |
Shipping
Our Services
Technical support
lFrom the date of purchase, two years of free repairs and maintenance;
lProviding technical updates and technical services at any time;
lThe software system will be upgraded for a lifetime to ensure the latest and full features of the software version for free.
lProvide technical training service according to customer’s requirements.
lCan choose freely different feeding board ways and feeder bases.
Service Support
lFrom the date of purchase, enjoy 24-hour service
lmake phone calls or on-site visits to customers non-scheduled , improve constantly according to the customer's requirements.
lGuarantee to the expiration date, free to provide customers with secure service.
